As a projector for the Event sector, the Christie Korus 4K1400-KS is equipped with 12000 ANSI lumens, a UHD (4K2K+) 3840 x 2400 resolution and a contrast of 25000:1. With its built-in laser light source, the projector achieves a manufacturer-stated lifespan of 20000 hours – calculating to 13.7 years at four hours of use per day. A major advantage for professional installations is the ability to use interchangeable lenses, allowing the projector to adapt to highly varied projection distances. Which optic is required for a specific case can easily be calculated via the Projector Calculator. Looking at practical performance, up to 803 cm can be illuminated with 12000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 535 cm. Should very large projection surfaces be required, the integrated edge-blending software offers the possibility to seamlessly combine images from multiple projectors without visible seams. For media input, video signals up to 1080P and 4K are supported. Regarding professional networking, the device offers a classic RJ45 LAN port for control alongside HDBaseT for the lossless transmission of picture and sound over long distances.
Display Type
1 x 0,8" HEP DMD DLP Chip UHD 4/3 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
12000
Screen
4000 Lux (200 cm Screen width)
Contrast
25000:1 dynamic contrast
25000:1 dynamic contrast
Black Level
0,4800 min. Lumen
0,16 min. Lumen
Offset
-
Resolution
UHD (4K2K+) 3840 x 2400
9.216.000 Pixel / WUXGA E-Shift
Event | Very large screen width and rooms with plenty of light and shaded daylight.
Light Source
Laser
Light Life
20000 h. / 50000 h. in Eco Mode
Operating Costs
0,00 € Laser
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux:
4000 Lux
Contrast:
25000:1
Candela pro m²:
1275 cd/m²
Foot-Lamberts:
372 fL
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
-
Connections
2x HDMI 2.0b(HDCP 1.4/2.2) in und 1x out
12G-SDI (BNC) in und out
Display Port (1.2a)
Audio Mini Jack in und out (Remote in)
USB 2.0 (Type A)
HDBaseT 3.0 (RJ45)
RS232
Full HD 1080P compatible User logo Eco Mode Kensington Slot High Dynamic Range (HDR) Warping Edge Blending PJLink™ Lan network compatible. Crestron®-Software compatible. Built-in Christie Twist? warping and blending optional Mystique? camera-based alignment Christie Intelligent Camera compatibility AMX 21:9 aspect ratio support and customize EDID Fade in & fade out control for shutter function
Full HD 1080P compatible
