The projector PU9220+ by Benq utilizes DLP technology and, according to the spec sheet, achieves 5000 ANSI lumens, a contrast of 4000:1 at a resolution of WUXGA 1920 x 1200. In operating mode, the installed projector lamp offers a lifespan of 1500 hours. To meet a wide variety of installation conditions, the projector offers the option of using different interchangeable lenses. Verifying the respective distances is easily possible via the Lens Calculator. Regarding projection size, the value of 5000 ANSI lumens allows for an image width of up to 718 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 479 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P. Furthermore, the model supports 360° projections for highly flexible deployment scenarios. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. This model dates back to 2015 and is no longer part of Benq's current product range.
Display Type
1 x 0,55" DLP Chip WUXGA 16/9 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
5000
Screen
2222 Lux (200 cm Screen width)
Contrast
4000:1 full on/off
4000:1 full on/off
Black Level
1,2500 min. Lumen
0,556 min. Lumen
Offset
-
Resolution
WUXGA 1920 x 1200
2.304.000 Pixel WUXGA 1920 x 1200 compressed
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Wide screen width or rooms with plenty of light (over 200 lumens).
Calculated brightness quality The screen width may also be larger. Perfect
Lux:
2222 Lux
Contrast:
4000:1
Candela pro m²:
706 cd/m²
Foot-Lamberts:
206 fL
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
-
Connections
HDMI 1.4 in
DVI-D in
D-sub 15pin in und out
5 x BNC RGBHV in
YUV in
Cinch Video in
Cinch Stereo in
S-Video in
Mini Jack Audio in und out
USB Typ A, B in
RS232C Din 9 pin in
RJ45 in
12V Trigger out
3D Sync out x 1
Full HD 1080P compatible
