The Benq MH856UST is a 3D-DLP projector that brings 3500 ANSI lumens, a HDTV 1920 x 1080 resolution alongside a contrast of 10000:1. The runtime of the lamp in this model is estimated at 3000 hours before a replacement is necessary. A special feature is the short-throw lens, which allows the device to be positioned at a very short distance from the screen. According to the data sheet, an image width of 2 meters is achieved from a distance of just 70 cm. Looking at practical performance, up to 601 cm can be illuminated with 3500 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 401 cm. Regarding signal processing, the model is compatible with incoming 1080P content as well as 3D. The built-in HDMI-MHL (Mobile High-Definition Link) port enables screen mirroring from a smartphone while simultaneously charging it. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. This model dates back to 2015 and is no longer part of Benq's current product range.
Display Type
1 x 0,55" DLP Chip HDTV 16/9 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3500
Screen
1556 Lux (200 cm Screen width)
Contrast
10000:1 full on/off
10000:1 full on/off
Black Level
0,3500 min. Lumen
0,156 min. Lumen
Offset
80% 34 cm over screen top edge →
SCREEN
+Projector
Resolution
HDTV 1920 x 1080
2.073.600 Pixel UXGA 1600 x 1200 compressed
Calculated brightness quality The screen width may also be larger. Perfect
70 cm (no Zoom)
Lux:
1556 Lux
Contrast:
10000:1
Candela pro m²:
497 cd/m²
Foot-Lamberts:
145 fL
90 cm
•
Focus
Manual
Zoom
No Zoom
Objective
F=2,5 f=5,1mm
Throw Ratio
0,35:1
Audio
2 x 10W
Connections
2 x HDMI mit MHL in
2 x D-sub 15pin in 1 x out
S-Video in
Cinch Video in
Cinch Stereo in
Mini Jack Audio in und out
USB Typ A,B in
RS232C Din 9 pin in
RJ45 in
Real Full HD 3D Full HD 1080P compatible Blank (Black screen button) Blackboard Modus Eco Mode Password protection Lan network compatible. Short-throw projector 6-segment colour wheel incl. wall bracket
Real Full HD 3D
