This projector from Benq utilizes 3D-BrilliantColor-DLP technology, achieving 3000 ANSI lumens and a contrast of 13000:1 at a resolution of WXGA 1280 x 800. The runtime of the lamp in this model is estimated at 4000 hours before a replacement is necessary. A daily usage of 2 hours makes an operational lifespan of 5.5 years possible. With its built-in wide-angle optics, the device belongs to the category of short-throw projectors. An image width of 2 meters is realized from a short distance of 98 cm. Looking at practical performance, up to 556 cm can be illuminated with 3000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 371 cm. Regarding signal processing, the model is compatible with incoming 1080P content. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. Equipped with a microphone jack and built-in speakers (10W), audio signals during presentations can be played back directly without an external audio system. This model dates back to 2012 and is no longer part of Benq's current product range.
Display Type
1 x 0,55" DLP Chip WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3000
Screen
1200 Lux (200 cm Screen width)
Contrast
13000:1 full on/off
13000:1 full on/off
Black Level
0,2308 min. Lumen
0,092 min. Lumen
Offset
55% 6 cm over screen top edge →
SCREEN
+Projector
Resolution
WXGA 1280 x 800
1.024.000 Pixel UXGA 1600 x 1200 compressed
Calculated brightness quality The screen width may also be larger. Perfect
98 cm (no Zoom)
Lux:
1200 Lux
Contrast:
13000:1
Candela pro m²:
380 cd/m²
Foot-Lamberts:
111 fL
69 cm
•
Focus
Manual
Zoom
No Zoom
Objective
F=2,6 f=6,9mm
Throw Ratio
0,49:1
Audio
1 x 10W
Connections
HDMI 1.3 in
2 x D-sub 15 pin in 1 x out
S-Video in
Cinch Video in
Cinch Stereo in
Mini Jack Audio in und out
RJ45 in
RS232C Din 9 pin in
USB Typ B
Mikrofon in
Full HD 1080P compatible
