Known as the F7600, this DLP projector by Acer features basic specs of 5000 ANSI lumens, a contrast of 2800:1 at a WUXGA 1920 x 1200 resolution. According to Acer, the included lamp lasts up to 1500 hours. Thanks to the combination of optical lens shift and digital keystone correction, the projected image's position can be adjusted very flexibly. The Projection Calculator helps find the optimal installation dimensions. A look at the light output reveals: The 5000 ANSI lumens are sufficient to illuminate an image width of up to 718 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 479 cm. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. This model dates back to 2016 and is no longer part of Acer's current product range.
Display Type
1 x DLP Chip WUXGA 16/9 Ti Digital Light Processing Chip
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Wide screen width or rooms with plenty of light (over 200 lumens).
Calculated brightness quality The screen width may also be larger. Perfect
Lux:
2222 Lux
Contrast:
2800:1
Candela pro m²:
706 cd/m²
Foot-Lamberts:
206 fL
56 cm
•
Focus
-
Zoom
-
Objective
-
Throw Ratio
-
Audio
-
Connections
HDMI in
DVI-D in
2 x D-sub 15pin in 1 x out
5 x BNC RGBHV in
YUV in
Cinch Video in
Cinch Stereo in
Mini Jack Audio in
USB Typ B in
RS232C Din 9 pin in
RJ45 in
12V Trigger out
3D Sync
Display Port
Lens shift Funktion
