Designed for the Event sector, the PLC XF47 model from Sanyo features 15000 ANSI lumens, a native XGA 1024 x 768 resolution and a contrast ratio of 2000:1. The manufacturer lists the lamp life at 1500 hours. Both optical image shifting (lens shift) and digital keystone adjustment are included, enabling exact alignment on the screen. The optical system is designed for the use of interchangeable lenses, allowing for a tailor-made configuration for almost any throw ratio. The Lens Calculator is available to calculate the exact dimensions. Regarding projection size, the value of 15000 ANSI lumens allows for an image width of up to 1067 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 711 cm. Regarding signal processing, the model is compatible with incoming 1080P content. Since entering the market in 2007, production has been discontinued; the manufacturer no longer actively offers the model. As an archive device, the projector remains highly relevant in our database.
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux:
5000 Lux
Contrast:
2000:1
Candela pro m²:
1593 cd/m²
Foot-Lamberts:
465 fL
75 cm
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
2 x 3W Stereo
Connections
1 x DVI-D (HDCP-kompatibel)
1 x D-Sub 15-pin (RGB analog)
5 x BNC (RGBHV / Video / Y, Cb / Pb, Cr / Pr)
1 x Mini DIN 4-pin (S-Video)
1 x D-Sub 9-pin (RS232 kompatibel)
1 x 3,5 mm Mini Jack (Fernbedienung)
1 x USB Typ B
Weitere Anschlüsse optional.
Ceiling Mounting
Yes, is possible.
Power
1700W
Size WxHxD
581 x 252 x 816 mm (22,9"x9,9"x32,1") 119,47 L/dm³
Operating Noise
46dB
Shift: 75 cm
Shift: 20 cm
Shift: 20 cm
Shift: 75 cm
Weight
36,50 kg / 80,47 lbs.
Keystone
Vert.: +/-40° Hori.: +/-20°
Illumination
90%
Frequenz
H-sync: 15-120 kHz V-sync: 48-120 Hz Range max.: 230 MHz
Full HD 1080P compatible Lens shift Funktion motorisch max. Freeze Blackboard Modus User logo Gamma correction 24/7 continuous operation capable Remote control with laser pointer und mouse control Optional LAN network compatible. Digital Zoom 3D-AUCC Intelligent Sharpness Optimisation RJ45 connection board optionally available Faroudja DCDi optionally available Adapts to all mains voltages. 10-bit digital gamma correction
Full HD 1080P compatible
