The projector PLC SW30 by Sanyo utilizes LCD technology and, according to the spec sheet, achieves 1200 ANSI lumens, a contrast of 400:1 at a resolution of SVGA 800 x 600. The runtime of the lamp in this model is estimated at 2000 hours before a replacement is necessary. Regarding projection size, the value of 1200 ANSI lumens allows for an image width of up to 302 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 201 cm. This model dates back to 2003 and is no longer part of Sanyo's current product range.
Display Type
3 x 0,55" LCD TFT Panel mit MLA SVGA 4/3 Liquid Crystal Display with Micro Lense Array
Ansi-Lumen
Projector
1200
Screen
400 Lux (200 cm Screen width)
Contrast
400:1 full on/off
400:1 full on/off
Black Level
3,0000 min. Lumen
1,008 min. Lumen
Offset
40% 15 cm under screen top edge →
SCREEN
+Projector
Resolution
SVGA 800 x 600
480.000 Pixel
XGA 1024 x 768 compressed
Video Modes
PAL / SECAM / NTSC / NTSC4.43 / PAL-M/N
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Small screen width, rooms with very little ambient light below 50 lumens.
1 x D-sub 15pin
1 x 3.5 mm Stereo Jack
1 x Component Input via D-sub 15pin(mit 3x RCA – D-Sub15 Kabel)1 x S-Video
1 x RCA (Composite Input)
1 x 3.5 mm Stereo Jack
1 x USB (type B)
1 x Control Port (RS232C)
Ceiling Mounting
Yes, is possible.
Power
244 / 169W in Eco Mode
Size WxHxD
270 x 78 x 190 mm (10,6"x3,1"x7,5") 4 L/dm³
Operating Noise
37 / 32 dB in Eco Mode
Key: 176 cm
Key: 56 cm
Weight
1,90 kg / 4,19 lbs.
Keystone
Vert.: +/-20°
Illumination
85%
Frequenz
H-sync: 15-80 kHz V-sync: 50-100 Hz Range max.: 100 MHz
So I am more than satisfied with the projector ... yes well the replacement bulb is a bit very expensive but on closer inspection almost all bulbs are priced at around 300 lobes.
the only drawback is that the tv lines are not sufficient from time to time and therefore the tv picture appears somewhat blurred. but as we are creatures of habit this is no longer noticeable after a while, eco mode is completely sufficient when it is dark clear and distinct presentation just simply top the device
pHiD
Autor:
Thomas Hempel 05.06.06
5
Stars
Good projector for the smaller purse
Also I have had the Sanyo PLC SW30 projector for about 3/4 of a year now and I have to say that I am very satisfied with it. I would definitely recommend this projector as it is available from approx. 480 eurons and is therefore also suitable for the smaller purse. Nevertheless, there is nothing to complain about the quality -FOR ME- except perhaps that the background looks a bit blurred so the further someone or something is the blurrier and can only be used to a limited extent in daylight because the Ansi lumens are not necessarily so strong (1200) so either darken or wait until it is dark (unfortunately shitty in summer) but I would like to say something else about that, unfortunately the remote control doesn‘t work for me, either I‘m too stupid or it‘s defective I don‘t know, but personally I don‘t need it because the little bit you might want to change on the picture can also be changed directly on the projector at the touch of a button, so the remote control is not absolutely necessary.
All in all a good projector and absolutely sufficient for normal home use. Furthermore, I only use the Eco mode that keeps the lamp longer and I personally even find the picture in eco mode is better than in normal but that‘s a matter of taste
Also have fun with the device you can strike with the device aufjeden case!!!
Freeze
