The technical data of the Panasonic PT-LMX460 includes 4600 ANSI lumens, a contrast of 3000000:1 as well as a XGA 1024 x 768 display. With its laser unit, the projector offers a specified light lifespan of 20000 hours, covering an estimated 13.7 years based on a 4-hour daily runtime. For basic image adjustment, the device is equipped with horizontal and vertical keystone correction, allowing digital compensation for trapezoidal distortion at angled projection setups. A look at the light output reveals: The 4600 ANSI lumens are sufficient to illuminate an image width of up to 591 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 394 cm. For media input, video signals up to 1080P are supported. An additional 360° projection capability allows the device to be oriented at almost any angle. As an additional feature, an integrated media player enables the direct playback of files without an external source device. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance.
Display Type
3 x 0,63" LCD Panel XGA 4/3 Liquid Crystal Display
Ansi-Lumen
Projector
4600
Screen
1533 Lux (200 cm Screen width)
Contrast
3000000:1 full on/off
3000000:1 full on/off
Black Level
0,0015 min. Lumen
0,001 min. Lumen
Offset
-
Resolution
XGA 1024 x 768
786.432 Pixel
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p Media player formats: jpeg, bmp, png, gif, tif,
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Wide screen width or rooms with plenty of light (over 200 lumens).
2x HDMI in (with HDCP, Deep Color, 4K/30p)
D-sub 15pin in und out
2x Mini Jack Audio in
1x Mini Jack Audio out
RS232C Din 9 pin in
RJ45 (10Base-T, 100Base-TX) in
USB TYP A in
Full HD 1080P compatible
