The projector LP810 by InFocus utilizes LCD technology and, according to the spec sheet, achieves 4100 ANSI lumens, a contrast of 800:1 at a resolution of XGA 1024 x 768. The manufacturer lists the lamp life at 2000 hours. For distortion-free image alignment, the projector offers both a lens shift function and keystone correction, granting significant leeway during mounting. The specifications identify the device as a model with an interchangeable lens option. Matching optional optics allow for exact adaptation to the required image size and projection distance, which can be calculated directly with the Projection Calculator. Regarding projection size, the value of 4100 ANSI lumens allows for an image width of up to 558 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 372 cm. This device is no longer manufactured and has been removed from InFocus's current lineup.
Display Type
3 x 1,3" LCD TFT Panel mit MLA XGA 4/3 Liquid Crystal Display with Micro Lense Array
XGA 1024 x 768
786.432 Pixel
SXGA 1280 x 1024 compressed
Video Modes
NTSC, NTSC 4.43, PAL, PAL-M, PAL-N,
Application
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Wide screen width or rooms with plenty of light (over 200 lumens).
Eingang 1: HD15/DVI-D (RGB analog
und digital), Audio ein (3,5 mm Eingang 2: 5 x BNC (RGBHV, RGsB,
RGBS, YPbPr, YCbCr), Audio ein (3,5 mmStereoanschluss); Eingang 3: RCA x 3, Composite/Component Video, S-Video RCA x 2,R/L Audio
Ceiling Mounting
Yes, is possible.
Power
380W
Size WxHxD
319 x 168 x 470 mm (12,6"x6,6"x18,5") 25,19 L/dm³
Operating Noise
35dB
Key: 319 cm Shift: 75 cm
Key: 67 cm
Key: 67 cm
Key: 319 cm
Weight
8,40 kg / 18,52 lbs.
Keystone
Vert.: +/-40° Hori.: +/-10°
Illumination
-
Frequenz
H-sync: 15-80 kHz V-sync: 50-120 Hz Range max.: 160 MHz
Lens shift Funktion
