According to Dukane, the ImagePro 68100-4KSS -L -B -BL model provides 10000 ANSI lumens, a contrast ratio of 10000:1 alongside a 4KESHIFT 2716 x 1528 resolution. This is a laser projector with a light source designed to last for 20000 hours, which translates to 13.7 years with 4 hours of daily use. To compensate for angled projection positions, the model features 2D keystone correction, which digitally corrects trapezoidal distortion. For maximum setup flexibility, the model supports optional interchangeable lenses, meaning the optics can be precisely matched to individual on-site requirements. Suitable distances can be determined using the Lens Calculator. A look at the light output reveals: The 10000 ANSI lumens are sufficient to illuminate an image width of up to 1016 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 677 cm. For media input, video signals up to 1080P and 4K as well as 3D are supported. Furthermore, the model supports 360° projections for highly flexible deployment scenarios. Connectivity for fixed installations is rounded off by an RJ45 port for remote maintenance and an HDBaseT interface, which transmits bundled video, audio, and control data over long cable runs. This model dates back to 2018 and is no longer part of Dukane's current product range.
Display Type
0,66" TRP DMD Chip 4KESH 16/9 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
10000
Screen
4444 Lux (200 cm Screen width)
Contrast
10000:1 full on/off
10000:1 full on/off
Black Level
1,0000 min. Lumen
0,445 min. Lumen
Offset
-
Resolution
4KESHIFT 2716 x 1528 4.150.048 Pixel
(4K2K) 3840 x 2160 mit E-Shift UHD (4K+2K) 4096 x 2160 compressed
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Very large screen width and rooms with plenty of light and shaded daylight.
Light Source
Laser
Light Life
20000 h.
Operating Costs
0,00 € Laser
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux:
4444 Lux
Contrast:
10000:1
Candela pro m²:
1415 cd/m²
Foot-Lamberts:
413 fL
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
-
Connections
2 x HDMI (V2.0) w/HDCP (V1.4/2.2)
Display Port
D-sub 15pin in
Quad 3G-SDI
USB in
RS232C Din 9 pin in
Mini Jack Audio in
Separate Sync / Composite Sync / Sync on G
RJ45 in
HDBaseT
Real Full HD 3D Full HD 1080P compatible Eco Mode 360° installable PJLink™ Lan network compatible. Crestron®-Software compatible. 681004KSS - White 681004KSSB - Black 681004KSSL - White w lens,TR 1.72.3:1 681004KSSBL - Black w lens,TR 1.72.3:1 AMX
Real Full HD 3D
Dukane Website
Product Sheet english
