Designed for the Standard-Portabel sector, the LV-X420 model from Canon features 4200 ANSI lumens, a native XGA 1024 x 768 resolution and a contrast ratio of 10000:1. To compensate for angled projection positions, the model features 2D keystone correction, which digitally corrects trapezoidal distortion. Looking at practical performance, up to 564 cm can be illuminated with 4200 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 376 cm. For media input, video signals up to 1080P as well as 3D are supported. The built-in HDMI-MHL (Mobile High-Definition Link) port enables screen mirroring from a smartphone while simultaneously charging it. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. This model dates back to 2017 and is no longer part of Canon's current product range.
Display Type
1 x 0,55" DLP Chip XGA 4/3 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
4200 / 3360 im Eco Mode
Screen
1400 Lux (200 cm Screen width)
Contrast
10000:1 full on/off
10000:1 full on/off
Black Level
0,4200 min. Lumen
0,14 min. Lumen
Offset
64% 21 cm over screen top edge →
SCREEN
+Projector
Resolution
XGA 1024 x 768
786.432 Pixel WUXGA 1920 x 1200 compressed
Standard-Portabel | External training and company presentations, as well as product presentations. Wide screen width or rooms with plenty of light (over 200 lumens).
Real Full HD 3D
Canon Website
Product Sheet english
