As a projector for the Micro-Portabel sector, the TOPTRO A1 is equipped with 1000 ANSI lumens, a HDTV 1920 x 1080 resolution and a contrast of 20000:1. The LED unit of this model is rated for up to 30000 hours of runtime. With four hours of daily operation, this corresponds to a period of 20.5 years. To ensure a rectangular image even with asymmetrical placement, the projector includes digital keystone correction for both the horizontal and vertical axes. Looking at practical performance, up to 321 cm can be illuminated with 1000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 214 cm. For media input, video signals up to 1080P and 4K are supported. As an additional feature, an integrated media player enables the direct playback of files without an external source device. Furthermore, the model is Bluetooth-enabled, allowing audio signals to be sent wirelessly to external speakers. Since the projector supports Miracast and Airplay screen mirroring, video signals can also be streamed wirelessly from the end device.
Display Type
1 x LCD Panel HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
1000
Screen
444 Lux (200 cm Screen width)
Contrast
20000:1
20000:1
Black Level
0,0500 min. Lumen
0,022 min. Lumen
Offset
-
Resolution
HDTV 1920 x 1080
2.073.600 Pixel UHD (4K2K) 3840 x 2160 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p Media player formats: Video Encoding MP4、MKV、WMV、3GP、MPG、TP、TS、DAT、FLV、TRP、MOV、VOB、VOP
Application
Micro-Portabel | Small mobile presentations. Small screen width, rooms with very little ambient light below 50 lumens.
Light Source
LED
Light Life
30000 h.
Operating Costs
0,00 € LED
Calculated brightness qualityGood (1.8)
272 cm (no Zoom)
Lux:
444 Lux
Contrast:
20000:1
Candela pro m²:
140 cd/m²
Foot-Lamberts:
41 fL
•
Focus
Automatic
Zoom
No Zoom 50%-100% Digital
Objective
-
Throw Ratio
1,36:1
Audio
2 x 10W
Connections
HDMI (ARC/CEC) in
Mini Jack Audio out
USB in
Bluetooth 5.2
Full HD 1080P compatible Integrated Mediaplayer High Dynamic Range (HDR) Wi-Fi network compatible. Netflix Certified Auto 6D Keystone Auto Screen Fit Auto Obstacle Avoidance
Full HD 1080P compatible
