Brief Introduction
Beta 2.5 |
Manufacturer Viewsonic offers the LSC601WU, an LCD laser projector with WUXGA 1920 x 1200 resolution and a contrast ratio of 300000:1. Manufacturer Viewsonic specifies the service life as 20,000 hours, which would be equivalent to over 13.7 years at 4 hours per day. The projector also offers a lens shift function for flexible projection adjustment without any loss of quality. An image width of up to 702 cm is possible; if the image width is smaller (we recommend max. 468 cm), even rooms with residual light are no problem. Even 1080P video signals are no problem for the projector, which even has the option of projecting HD 1080P Blu-rays onto the ceiling thanks to its 360? projection.
|
| Display Type |
3 x 0,64" LCD Panel with MLA
WUXGA 16/9 Liquid Crystal Display with Micro Lense Array
|
| Ansi-Lumen |
Projector |
6000 |
Screen |
2667 Lux (200 cm Screen width) |
| Contrast |
300000:1 |
300000:1
|
| Black Level |
0,0200 min. Lumen |
0,009 min. Lumen |
| Lens shift |
Vert.: +45% -0% Hori.: +/-21%
|
| Resolution |
WUXGA 1920 x 1200
2.304.000 Pixel |
| Video Modes |
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p |
| Application |
Stationary | Permanent installation in the training room and meeting room as well as the conference room.
Very large screen width and rooms with plenty of light and shaded daylight. |
| Light Source |
Laser Phosphor
|
|
| Light Life |
20000 h. / 30000 h. in Eco Mode |
| Operating Costs |
0,00 € Laser
|
|
216 - 352 cm
|
 |
|
Lux: |
2667 Lux |
|
Room light max.: |
533 Lux |
|
Candela pro m²: |
850 cd/m² |
|
Foot-Lamberts: |
248 fL |
|
 |
| 51 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Powered |
| Zoom |
Powered x1,6 |
| Objective |
F=1,58-2,02 f=15,3-24,6 mm |
| Throw Ratio |
1,08-1,76:1 show |
| Audio |
1 x 16W |
| Connections |
2x HDMI 1.4 (HDCP 1.4) in
D-sub 15pin in und out
Mini Jack Audio in und out
S/PDIF
USB-A in
USB-B in
RS232C Din 9 pin in
RJ45 in
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
330W |
| Size WxHxD |
405 x 137 x 358 mm (15,9"x5,4"x14,1") 19,86 L/dm³
|
| Operating Noise |
35 / 25 dB in Eco Mode |
Key: 125 cm
Shift: 51 cm |
Key: 101 cm
Shift: 42 cm |
| Key: 101 cm
Shift: 42 cm |
| |
|
|
| Weight |
7,90 kg / 15,43 lbs. |
| Keystone |
Vert.: +/-30°
Hori.: +/-25°
|
| Illumination |
- |
| Frequenz |
H-sync: 15-100 kHz
V-sync: 23-85 Hz
|
| Foot-Lamberts |
248 fL
/ max. 787 cm screen width |
| Candela m² |
850 cd/m² |
| Features |
 Full HD 1080P compatible
Lens shift Funktion
Eco Mode
Kensington Slot
360° installable
Password protection
PJLink™
Control via web browser
Lan network compatible.
Crestron®-Software compatible.
ATEN and Extron systems compatible
|
|
Optional only
Google TV /
Fire TV /
Apple TV /
Roku TV /
Xiaomi TV Ads |
In Comparison
The Viewsonic LSC601WU compared to others current "Stationary" projectors. |
| Ansi-Lumen: |
|
59 |
Weight: |
|
99 |
| Contrast: |
|
6 |
dB: |
|
58 |
| Black level: |
|
100 |
Power cons.: |
|
89 |
| Picture Total Points: | 55 |
Projector Total Points: | 82 |
|
| Popularity Top 100 |
|
| Points: |
|
11 |
| Ranking: |
182 (From: 231) |
|
|
|
|
|
| Status |
2024 Current model // Last update of the data: 2024-09-30
Created: 2024-09-26 11:16:19
|
| Data |
 Product Sheet english HC
Quick Start Guide
User Manual english (28.6 MB)

|
Viewsonic Website
