Brief Introduction
Beta 2.5 |
The standard portable HZ40HDR 3D laser DLP has 4000 Ansi lumens, a contrast of 1800:1 and an HDTV 1920 x 1080 resolution. The manufacturer Optoma specifies a service life of 30,000 hours, which is equivalent to over 20.5 years at 4 hours per day. As the projector has horizontal and vertical keystone correction, the projector can be set up with plenty of free space in the room. Thanks to the brightness of 4000 Ansi lumens, a picture width of 643 cm is possible. The projector can also handle slightly brighter rooms with a narrower picture width (we recommend a maximum of 429 cm). Video signals 1080P and 4K (compressed) as well as 3D are also no problem for the projector, meaning that all Blu-ray formats currently available can be recognized by the projector.
|
| Display Type |
1 x DLP Chip
HDTV 16/9 Ti Digital Light Processing Chip
|
| Ansi-Lumen |
Projector |
4000 |
Screen |
1778 Lux (200 cm Screen width) |
| Contrast |
1800:1 full on/off |
1800:1 full on/off
|
| Black Level |
2,2222 min. Lumen |
0,989 min. Lumen |
| Offset |
66% show
|
| Resolution |
HDTV 1920 x 1080
2.073.600 Pixel
UHD (4K+2K) 4096 x 2160 compressed |
| Video Modes |
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), 3D, EDTV 480p, 576p |
| 3D Compatibility |
Frame-Packing (Full HD 3D) | Side-by-Side | Top-and-Bottom
Frame Sequential (3D Ready) |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Wide screen width or rooms with plenty of light (over 200 lumens). |
| Light Source |
Laser
|
|
| Light Life |
30000 h. |
| Operating Costs |
0,00 € Laser
|
|
296 - 324 cm
|
 |
|
Lux: |
1778 Lux |
|
Room light max.: |
356 Lux |
|
Candela pro m²: |
565 cd/m² |
|
Foot-Lamberts: |
165 fL |
|
 |
| 74 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
No Zoom 1,09 |
| Objective |
f=12,81-16,74 mm |
| Throw Ratio |
1,48-1,62:1 show |
| Audio |
1 x 15W |
| Connections |
2x HDMI in
Mini Jack Audio out
USB in
RS232C Din 9 pin in
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
173W |
| Size WxHxD |
274 x 114 x 216 mm (10,8"x4,5"x8,5") 6,75 L/dm³
|
| Operating Noise |
34 / 32 dB in Eco Mode |
Key: 245 cm |
Key: 171 cm |
| Key: 171 cm |
| |
|
|
| Weight |
3,00 kg / 6,61 lbs. |
| Keystone |
Vert.: +/-30°
Hori.: +/-30°
|
| Illumination |
75% |
| Frequenz |
H-sync: 15-140 kHz
V-sync: 24-120 Hz
|
| Foot-Lamberts |
165 fL
/ max. 643 cm screen width |
| Candela m² |
565 cd/m² |
| Features |
 Real Full HD 3D
Full HD 1080P compatible
Eco Mode
Kensington Slot
360° installable
24/7 continuous operation capable
|
|
Optional only
Google TV /
Fire TV /
Apple TV /
Roku TV /
Xiaomi TV Ads |
In Comparison
The Optoma HZ40HDR compared to others current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
56 |
Weight: |
|
77 |
| Contrast: |
|
1 |
dB: |
|
65 |
| Black level: |
|
74 |
Power cons.: |
|
80 |
| Picture Total Points: | 44 |
Projector Total Points: | 74 |
|
| Popularity Top 100 |
|
| Points: |
|
5 |
| Ranking: |
171 (From: 849) |
|
|
|
|
|
| Status |
2022 Current model // Last update of the data: 2024-11-01
