Brief Introduction
Beta 2.5 |
The Whiteboard EW695UTis 3D BrilliantColor DLP projector from Optoma has 3500 Ansi lumens, a contrast of 3000:1 and a WXGA 1280 x 800 resolution. Thanks to the brightness of 3500 Ansi lumens, an image width of 601 cm is possible. The projector will also create slightly brighter rooms with a smaller image width (we recommend max. 401 cm). The projector is equipped with an integrated whiteboard function for interactive training and presentations. Even 1080P playback is no problem for the projector. On the market since 2013, the model is no longer offered by the manufacturer Optoma, but is still very popular in our projector database.
|
| Display Type |
1 x 0,65" DC3 DLP Chip
WXGA 16/10 Ti Digital Light Processing Chip
|
| Ansi-Lumen |
Projector |
3500 |
Screen |
1400 Lux (200 cm Screen width) |
| Contrast |
3000:1 full on/off |
3000:1 full on/off
|
| Black Level |
1,1667 min. Lumen |
0,467 min. Lumen |
| Offset |
75% show
|
| Resolution |
WXGA 1280 x 800
1.024.000 Pixel
UXGA 1600 x 1200 compressed |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p |
| 3D Compatibility |
| Frame Sequential (3D Ready) |
|
| Application |
Whiteboard | Training and company presentations, as well as product presentations.
Medium screen width or rooms with a little more ambient light, max. 200 lumens. |
| Light Source |
280W P-VIP Lamp
Article Nr.: SP.8JR03GC01
|
|
| Light Life |
2000 h. 3000 h. in Eco Mode |
| Operating Costs |
-
|
|
60 cm (no Zoom)
|
 |
|
Lux: |
1400 Lux |
|
Room light max.: |
280 Lux |
|
Candela pro m²: |
445 cd/m² |
|
Foot-Lamberts: |
130 fL |
|
 |
| 94 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
No Zoom |
| Objective |
F=2,71 f=4,415mm |
| Throw Ratio |
0,30:1 |
| Audio |
2 x 5W |
| Connections |
HDMI 1.3 in
2 x D-sub 15 pin in 1 x out
S-Video in
Cinch Video in
Mini Jack Audio in
RJ45 in
RS232C
12V Trigger out
Mini USB |
| Ceiling Mounting |
Yes, is possible. |
| Power |
365 / 325W in Eco Mode |
| Size WxHxD |
427 x 203 x 407 mm (16,8"x8"x16") 35,28 L/dm³
|
| Operating Noise |
32 / 30 dB in Eco Mode |
|
| Weight |
7,60 kg / 16,76 lbs. |
| Keystone |
- |
| Illumination |
85% |
| Frequenz |
H-sync: 15,3-91,1 kHz
V-sync: 24-120 Hz
|
| Foot-Lamberts |
130 fL
/ max. 601 cm screen width |
| Candela m² |
445 cd/m² |
| Features |
 Full HD 1080P compatible
Freeze
Blackboard Modus
Eco Mode
Kensington Slot
sRGB
Gamma correction
Digital image shift
Password protection
BrilliantColor™
Remote control with laser pointer und mouse control
Control via web browser
Lan network compatible.
Short-throw projector
Crestron®-Software compatible.
Digital Zoom
With Interactive Pen.
Model “M is with Bracket.
Whiteboard Function
|
|
Optional only
Google TV /
Fire TV /
Apple TV /
Roku TV /
Xiaomi TV Ads |
In Comparison
The Optoma EW695UTis compared to others not current "Whiteboard" projectors. |
| Ansi-Lumen: |
|
34 |
Weight: |
|
96 |
| Contrast: |
|
1 |
dB: |
|
72 |
| Black level: |
|
97 |
Power cons.: |
|
96 |
| Picture Total Points: | 44 |
Projector Total Points: | 88 |
|
| Popularity Top 100 |
|
| Points: |
|
20 |
| Ranking: |
227 (From: 297) |
|
|
|
|
|
| Status |
2013 Discontinued (EOL) // Last update of the data: 2023-08-04
Created: 2013-01-08 11:46:20
|
| Data |
 Product Sheet english
Product Sheet english HC
User Manual english (14.16 MB)

|
Optoma Website
